KPX-D65P 60hz 52kw 65kva Deutz Engine BF4M2012 Diesel Generator

GENERATOR SET SPECIFICATIONS   Frequency: 50HZ   Model: KP-D750P   Prime Power (kVA/kW): 600/750   Standby Power (kVA/kW): 660/825   Fuel cons 100%(L/H): 154.8     ENGINE：   Powered by:  Deutz   Engine Model: HC12V132ZL-LAG2A     ALTERNATOR：   Exciter type: Brushless, self-excited   Insulation grade: H   Protection grade: IP23​

GENERATOR SET SPECIFICATIONS   Frequency: 60HZ   Model: KPX-D100P   Prime Power (kVA/kW): 80/100   Standby Power (kVA/kW): 88/110   Fuel cons 100%(L/H): 24.4     ENGINE：   Powered by:  Deutz   Engine Model: BF4M2012C G2     ALTERNATOR：   Exciter type: Brushless, self-excited   Insulation grade: H   Protection grade: IP23​

GENERATOR SET SPECIFICATIONS   Frequency: 60Hz   Model: KPX-YC250P   Prime Power (kW/kVA): 200/250   Standby Power (kW/kVA): 220/275   Fuel cons 100%(L/H): 59.3     ENGINE：   Powered by:  YUCHAI   Engine Model: YC6MK360L-D20   ALTERNATOR：   Exciter type: Brushless, self-excited   Insulation grade: H   Protection grade: IP23​

GENERATOR SET SPECIFICATIONS   Frequency: 50Hz   Model: KP-C1540P   Prime Power (kW/kVA): 1232/1540   Standby Power (kW/kVA): 1360/1700   Fuel cons 100%(L/H): 338     ENGINE：   Powered by:  Cummins   Engine Model: QSK50-G4     ALTERNATOR：   Exciter type: Brushless, self-excited   Insulation grade: H   Protection grade: IP23​

GENERATOR SET SPECIFICATIONS   Frequency: 50Hz   Model: KP-W80P   Prime Power (kW/kVA): 64/80   Standby Power (kW/kVA): 70/87.5   Fuel cons 100%(L/H): 18.9     ENGINE：   Powered by: Weichai   Engine Model: WP4.1D80E200     ALTERNATOR：   Exciter type: Brushless, self-excited   Insulation grade: H   Protection grade: IP23​

GENERATOR SET SPECIFICATIONS   Frequency: 50Hz   Model: KP-V135P   Prime Power (kW/kVA): 108/135   Standby Power (kW/kVA): 118/147   Fuel cons 100%(L/H): 28     ENGINE：   Powered by:  Volvo   Engine Model: TAD582VE     ALTERNATOR：   Exciter type: Brushless, self-excited   Insulation grade: H   Protection grade: IP23​

Dimensions   Expand Working Dimension 3350*2550*7500mm Package Dimensions 2250*1200*1980mm Weight 840KG Max. # of units loading 22 units / 40HQ Engine   Engine model KUBOTA D1105 Cooling system water cool Fuel Type DIESEL  Bore*Stroke(mm) 3-78*78.5 Displacement  1.21L Speed 1500RPM Alternator   Power  8KW  Voltage and frequency 110 & 270V/50 & 60hz Phase single Output 230V Excitation model  Brushless Mast & Lights   Max.Height 7.5M telescoping rotating tower Sections 5 SECTIONS Feature 360 rotation  Lifting system Electric Fooldlight LED Lamp 4x400w Total lumens 4x52000lum Control Panel   Brand SMART GEN 5 Start style Electric start Battery  12V Digital Hour meter YES Operation monitoring YES Fuel System   Material Iron Capacity 120L Runing time 90H Trailer   Windproof class ＜102km/h Trailler Suspension & Axle With Brakes Leaf Springs&single axle without brake Tow Bar Retractable &Adjustable Supporting Wheel towbar Stabilizing Legs & Number 4 pcs drawable bar with manual jacks Wheel's rim size & Tires 14INCH & 185 Tow a Adapter 50mm ball adapter Tail Lights Tail Reflector Max Towing Speed 60km/h Extinguisher yes ​

SPECIFICATIONS   Model: KPLB-300   Capacity: 300kW   Type of load: Resistive   Power factor: 1   Number of fans: 4   Dimension (mm): 1690*1440*1750   Weight (kg): 1085​
